Subwoofer

hd Sub12

  • HARMONIC DESIGN

  • 제조국 : Made in Germany

Subwoofer hd Sub12

기능 및 특성

  • slave subwoofer for hd P12stereo
  • compact dimensions
  • ergonomic carrying handles
  • robust multiplex housing with textured paint
  • rubber surround for precise LF reproduction
  • stand-alone or cardioid subwoofer array
  • extends the frequency response below 40 Hz
  • RAL colors available

Technical Data

  • Acoustic design Bass reflex

  • Transducers : 1x 12“-long-excursion ferrite woofer

  • Impedance : 8 Ω

  • Crossover variable according to the preset

  • Coverage (hor x ver) : omnidirectional, cardioid with preset

  • Frequency range (-6dB) : 40 Hz – 180 Hz

  • Sensitivity (1W / 1m) : 98 dB

  • Power Rating AES / Peak : 400 / 800 W

  • SPLmax @ 10% THD : 122 dB

  • Enclosure r: obust multiplex housing with Warnex textured paint black, recessed connection panel with 2x NL4, M20 thread, 2x carrying handle, steel grille with acoustic foam inside

  • Weight : 19 kg

  • Dimensions (W x H x D) : 400 x 430 x 420 mm
