Subwoofer

hd Sub18

  • HARMONIC DESIGN

  • 제조국 : Made in Germany

Subwoofer hd Sub18

기능 및 특성

  • compact dimensions
  • high efficiency, long throw range
  • passive crossover for best economy
  • Power handling 600 W / 2400 W (AES / Peak)
  • coverage 90° x 15° or 120° x 15°
  • linear sound
  • big headroom thanks to 2x HF driver / module
  • integrated 3-point FastRig rigging

Technical Data

  • Acoustic design : LineSource / Bassreflex

  • Transducers : 1x 12“N LF / 2x 1.4“N HF

  • Impedance : LF: 8 Ω, HF: 8 Ω

  • Crossover : passive, 900 Hz

  • Coverage (hor x ver) : 90° x 15° or 120° x 15°, choose on order

  • Frequency range (-6dB) : 45 Hz – 20 kHz

  • Sensitivity (1W / 1m) : 105 dB

  • Power Rating AES / Peak : 600 / 2400 W

  • SPLmax @ 10% THD : 138 dB

  • Enclosure : Robust multiplex housing with polyurethane coating black, recessed connection panel with 2x NL4, transport handles, integrated rigging, steel grille with acoustic foam

  • Weight : 28 kg

  • Dimensions (W x H x D) : 575 x 340 x 430 mm
